804-000 - Door shell with installation parts Door lock
Porsche 2016 (981 Cayman GT4) Door shell with installation parts Door lock Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 98153191103GRV
DOOR SHELL LEFT ALSO USE: 000 043 204 38 - PRIMED
This part replaces part number 98153191103
# 1
MPN: 98153191203GRV
DOOR SHELL RIGHT ALSO USE: 000 043 204 38 - PRIMED
Supersession
Supersession
This part replaces part number 98153191203
# 2
MPN: 99153131900
HINGE LEFT
Supersession
Supersession
# 2
MPN: 99153132000
HINGE RIGHT
Supersession
Supersession
# 3
MPN: 99907319201
SOCKET HEAD BOLT M8X33-ASP
# 4
MPN: 99153715100
DOOR CATCH
Supersession
Supersession
# 6
MPN: 99907604201
HEXAGON NUT M6-S-SC
# 7
MPN: 99907313801
flat round head bolt M8X25-PA
from £0.91
from £0.91
# 8
MPN: 95853794700
COVER CAP HINGE
from £0.85
from £0.85
# 9
MPN: N 91017401
COUNTERSUNK MULTI-POINT M8X22 SOCKET HEAD BOLT
from £0.78
from £0.78
# 10
MPN: 3C0837767A
STRIKER
Supersession
Supersession
# 12
MPN: 981537831001E0
SUPPORT LEFT WING - BLACK
from £11.83
from £11.83
This part replaces part number 98153783100
# 12
MPN: 981537832001E0
SUPPORT RIGHT WING - BLACK
from £12.43
from £12.43
This part replaces part number 98153783200
# 13
MPN: 99907332202
FILLISTER HD. BOLT M6X20
Supersession
Supersession
# 14
MPN: 8J1837015E
DOOR LOCK LEFT LHD
P534 (Theft security system, 433 MHz) | P098 (Left-hand drive version)
from £187.98
from £187.98
# 14
MPN: 8J1837016E
DOOR LOCK RIGHT LHD
P534 (Theft security system, 433 MHz) | P098 (Left-hand drive version)
from £175.76
from £175.76
# 14
MPN: 8J1837016F
DOOR LOCK RIGHT
P without 534
from £527.71
from £527.71
# 14
MPN: 8J2837015E
DOOR LOCK LEFT RHD
P534 (Theft security system, 433 MHz) | P099 (Right-hand drive version)
from £175.76
from £175.76
# 14
MPN: 8J2837016E
DOOR LOCK RIGHT RHD
P534 (Theft security system, 433 MHz) | P099 (Right-hand drive version)
from £580.92
from £580.92
# 15
MPN: WHT003688
FILLISTER HEAD BOLT (COMBI.) M8X16
from £1.06
from £1.06
# 16
MPN: 99153731900
BOWDEN CABLE DOOR LOCK
from £11.04
from £11.04
# 17
MPN: 99153704501
DOOR LOCK COVER LHD (DRIVERS SIDE)
P098 (Left-hand drive version)
from £6.82
from £6.82
# 17
MPN: 99153704601
DOOR LOCK COVER RHD (DRIVERS SIDE)
P099 (Right-hand drive version)
from £6.82
from £6.82
# 18
MPN: N 01021813
HEXAGON BOLT M6X25
from £0.52
from £0.52
# 19
MPN: 99908421203
HEXAGON NUT M6
from £0.91
from £0.91
