porsche 2020 (718 cayman) exhaust system parts diagram

202-003 - Exhaust System

Porsche 2020 (718 Cayman) exhaust system Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 982254017F
                                  EXHAUST MANIFOLD WITH LEFT CATALYTIC CONVERTER
                                  from £2,258.73
                                  from £2,258.73
                                  MANIFOLD Genuine Porsche Part - New (to order)
                                  # 1
                                  MPN: 982254017FX
                                  EXHAUST MANIFOLD WITH LEFT CATALYTIC CONVERTER
                                  from £2,258.73
                                  from £2,258.73
                                  MANIFOLD Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 982254018F
                                  EXHAUST MANIFOLD WITH RIGHT CATALYTIC CONVERTER
                                  from £2,258.73
                                  from £2,258.73
                                  MANIFOLD Genuine Porsche Part - New (to order)
                                  # 2
                                  MPN: 982254018FX
                                  EXHAUST MANIFOLD WITH RIGHT CATALYTIC CONVERTER
                                  from £2,258.73
                                  from £2,258.73
                                  MANIFOLD Genuine Porsche Part - New (to order)
                                  # 3
                                  MPN: 982251261
                                  SEAL
                                  from £26.21
                                  from £26.21
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 4
                                  MPN: 9A700384201
                                  HEXAGON NUT
                                  from £2.66
                                  from £2.66
                                  HEX. NUT Genuine Porsche Part - New (to order)
                                  # 5
                                  MPN: PAF008146
                                  HEXAGON HEAD BOLT M8X25
                                  from £1.34
                                  from £1.34
                                  HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: 99711111300
                                  SEAL
                                  SEAL
                                  from £7.66
                                  from £7.66
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: 982251263A
                                  SEAL
                                  SEAL
                                  from £22.48
                                  from £22.48
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 6
                                  MPN: 982251263B
                                  SEAL
                                  from £22.48
                                  from £22.48
                                  SEAL Genuine Porsche Part - New (to order)
                                  # 7
                                  MPN: 90091000303
                                  HEXAGON NUT M8
                                  from £2.29
                                  from £2.29
                                  hex. nut - M 8 Genuine Porsche Part - New In stock
                                  # 7
                                  MPN: 99908003700
                                  SCREW BOLT M8
                                  from £10.80
                                  from £10.80
                                  EPRS-SHR M 8X3 Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 982 254 351 P
                                  Exhaust pipe left Exh. pipe with particul. filt.
                                  Exhaust pipe left Exh. pipe with particul. filt.
                                  Exhaust pipe left Exh. pipe with particul. filt. Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 982254351R
                                  Exhaust pipe left Exh. pipe with particul. filt.
                                  P4BF (Emission standard EU6 DG) | P4BI (Emission standard EU6 AP)
                                  from £2,072.24
                                  from £2,072.24
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 8
                                  MPN: 982254351T
                                  EXHAUST PIPE LEFT
                                  P160 (EU4 emissions concept without EOBD) | P165 (Emission standard EU5) | P7CE (Emission standard LEV 3/Tier 3 70) | P7MM (EU6 plus exhaust concept)
                                  from £2,311.66
                                  from £2,311.66
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 982 254 350 P
                                  EXHAUST PIPE RIGHT EXH. PIPE WITH PARTICUL. FILT.
                                  EXHAUST PIPE RIGHT EXH. PIPE WITH PARTICUL. FILT.
                                  Exhaust pipe left Exh. pipe with particul. filt. Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 982254350R
                                  EXHAUST PIPE RIGHT EXH. PIPE WITH PARTICUL. FILT.
                                  P4BF (Emission standard EU6 DG) | P4BI (Emission standard EU6 AP)
                                  from £2,072.24
                                  from £2,072.24
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 9
                                  MPN: 982254350T
                                  EXHAUST PIPE RIGHT
                                  P160 (EU4 emissions concept without EOBD) | P165 (Emission standard EU5) | P7CE (Emission standard LEV 3/Tier 3 70) | P7MM (EU6 plus exhaust concept)
                                  from £2,311.66
                                  from £2,311.66
                                  EXHAUST PIPE Genuine Porsche Part - New (to order)
                                  # 10
                                  MPN: 982251263A
                                  SEAL
                                  from £22.48
                                  from £22.48
                                  GASKET Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 982251053E
                                  SILENCER
                                  SILENCER
                                  from £1,948.40
                                  from £1,948.40
                                  SILENCER Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 982251053F
                                  SILENCER
                                  SILENCER
                                  from £1,948.40
                                  from £1,948.40
                                  SILENCER Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 982251053H
                                  SILENCER
                                  SILENCER
                                  from £2,077.12
                                  from £2,077.12
                                  SILENCER Genuine Porsche Part - New (to order)
                                  # 11
                                  MPN: 982251053K
                                  SILENCER
                                  from £2,298.22
                                  from £2,298.22
                                  SILENCER Genuine Porsche Part - New (to order)
                                  # 11
                                  -
                                  VACUUM UNIT SEE ILLUSTRATION: 202-020
                                  # 12
                                  MPN: PAF007634
                                  HEXAGON FLANGE NUT, M8 SELF-LOCKING
                                  from £6.78
                                  from £6.78
                                  This part replaces part number 99908464202
                                  HEXAGON FLANGE NUT, Genuine Porsche Part - New (to order)
                                  # 12
                                  MPN: 90008105901
                                  THREADED PIN M8X22
                                  Supersession
                                  Supersession
                                  Genuine Porsche Part (no longer available to order)
                                  # 13
                                  MPN: 982251187AH
                                  EXHAUST TAIL PIPE LEFT BLACK/CHROME
                                  from £420.29
                                  from £420.29
                                  EXHAUST TAIL PIPE Genuine Porsche Part - New (to order)
                                  # 14
                                  MPN: 982251188C
                                  EXHAUST TAIL PIPE RIGHT BLACK/CHROME
                                  from £502.61
                                  from £502.61
                                  EXHAUST TAIL PIPE Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 982251255G
                                  BRACKET FOR EXHAUST SILENCER - PDK -
                                  from £201.98
                                  from £201.98
                                  BRACKET FOR EXHAUST SILENCER Genuine Porsche Part - New (to order)
                                  # 15
                                  MPN: 982251255F
                                  BRACKET FOR EXHAUST SILENCER MANUAL GEARBOX
                                  from £199.60
                                  from £199.60
                                  BRACKET FOR EXHAUST SILENCER Genuine Porsche Part - New (to order)
                                  # 16
                                  MPN: 982251519
                                  BRACKET
                                  from £144.16
                                  from £144.16
                                  BRACKET Genuine Porsche Part - New (to order)
                                  # 17
                                  MPN: PAF007634
                                  HEXAGON FLANGE NUT, M8 SELF-LOCKING
                                  from £6.78
                                  from £6.78
                                  This part replaces part number 99908464202
                                  HEXAGON FLANGE NUT, Genuine Porsche Part - New (to order)
                                  # 18
                                  MPN: 9A700407600
                                  TORX SCREW M8X16
                                  from £0.90
                                  from £0.90
                                  This part replaces part number 99907345801
                                  TORX SCREW Genuine Porsche Part - New (to order)
                                  # 19
                                  MPN: 90038527401
                                  TORX SCREW M10X25
                                  from £0.91
                                  from £0.91
                                  TORX SCREW Genuine Porsche Part - New (to order)
                                  # 20
                                  MPN: 9A7906262
                                  LAMBDA PROBE (IN FRONT OF CATALYST)
                                  LAMBDA PROBE (IN FRONT OF CATALYST)
                                  from £148.96
                                  from £148.96
                                  OXYGEN SENSOR Genuine Porsche Part - New (to order)
                                  # 20
                                  MPN: 0PB906262L
                                  LAMBDA PROBE (IN FRONT OF CATALYST)
                                  from £175.62
                                  from £175.62
                                  LAMBDA PROBE Genuine Porsche Part - New (to order)
                                  LAMBDA PROBE Genuine Lamborghini - New (to order)
                                  # 21
                                  MPN: 9A7906265F
                                  Lambda probe (behind catalyst)
                                  Lambda probe (behind catalyst)
                                  from £150.48
                                  from £150.48
                                  OXYGEN SENSOR Genuine Porsche Part - New (to order)
                                  # 21
                                  MPN: 0PB906265J
                                  Lambda probe (behind catalyst)
                                  from £175.62
                                  from £175.62
                                  LAMBDA PROBE Genuine Porsche Part - New (to order)
                                  # 22
                                  MPN: 982971846A
                                  HOLDER FOR LAMBDA PROBE
                                  from £13.97
                                  from £13.97
                                  BRACKET FOR OXYGEN SENSOR Genuine Porsche Part - New (to order)
