porsche 2020 (718 cayman) cross member parts diagram

812-005 - CROSS MEMBER

Porsche 2020 (718 Cayman) Cross member Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: 98158015100
          CROSS MEMBER
          from £178.12
          from £178.12
          CROSS MEMBER Genuine Porsche Part - New (to order)
          # 2
          MPN: 90038513301
          HEXAGON HEAD BOLT M10X50
          from £2.12
          from £2.12
          HEXAGON HEAD BOLT Genuine Porsche Part - New (to order)
          # 3
          MPN: 99907206601
          HEXAGON BOLT M10X80
          from £2.84
          from £2.84
          SCREW, HEX. HD Genuine Porsche Part - New (to order)
          # 4
          MPN: 98158021300
          SUPPORT FOR CROSS MEMBER LEFT
          SUPPORT FOR CROSS MEMBER LEFT
          from £389.74
          from £389.74
          MOUNTING FOR CROSS MEMBER Genuine Porsche Part - New (to order)
          # 4
          MPN: 98158021301
          SUPPORT FOR CROSS MEMBER LEFT
          from £427.51
          from £427.51
          SUPPORT FOR CROSS MEMBER Genuine Porsche Part - New (to order)
          # 4
          MPN: 98158021400
          SUPPORT FOR CROSS MEMBER RIGHT
          from £427.51
          from £427.51
          MOUNTING FOR CROSS MEMBER Genuine Porsche Part - New (to order)
          # 5
          MPN: 90037834801
          HEXAGON BOLT AM10X55
          from £1.62
          from £1.62
          SCREW, HEX. HD Genuine Porsche Part - New (to order)
