porsche 2021 (718 cayman gt4) wheel carrier wheel hub parts diagram

401-050 - Wheel carrier Wheel hub

Porsche 2021 (718 Cayman GT4) Wheel carrier Wheel hub Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 1
                          MPN: 99134195780
                          WHEEL CARRIER LEFT FRONT AXLE
                          from £473.53
                          from £473.53
                          wheel carrier Genuine Porsche Part - New (to order)
                          # 1
                          MPN: 99134195880
                          WHEEL CARRIER RIGHT FRONT AXLE
                          from £473.53
                          from £473.53
                          wheel carrier Genuine Porsche Part - New (to order)
                          # 2
                          MPN: 95833158300
                          ANGULAR BALL BEARING ALSO USE: 8X WHT 004 835 2X WHT 007 021
                          from £137.75
                          from £137.75
                          BALL BEARING Genuine Porsche Part - New (to order)
                          # 3
                          MPN: WHT004835
                          BALL SCREW M12X1,25X45
                          from £3.83
                          from £3.83
                          BALL SCREW Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 992501651D
                          WHEEL HUB
                          from £281.93
                          from £281.93
                          WHEEL HUB Genuine Porsche Part - New (to order)
                          # 4
                          MPN: 9GT407615A
                          WHEEL HUB
                          PE1T (RS version)
                          from £327.21
                          from £327.21
                          WHEEL HUB Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 9GT407123
                          STUB AXLE
                          from £166.37
                          from £166.37
                          This part replaces part number 99134113180
                          STUB AXLE Genuine Porsche Part - New (to order)
                          # 5
                          MPN: 9GT407123A
                          STUB AXLE
                          PE1T (RS version)
                          from £175.74
                          from £175.74
                          STUB AXLE Genuine Porsche Part - New (to order)
                          # 6
                          MPN: WHT007021
                          HEX. NUT, SELF-LOCKING WITH M22X1.5 WASHER
                          from £7.88
                          from £7.88
                          HEX. NUT, SELF-LOCKING WITH WASHER, M22 X 1.5 Genuine Porsche Part - New (to order)
                          # 7
                          MPN: 99160640701
                          SPEED SENSOR
                          from £100.50
                          from £100.50
                          SPEED SENSOR Genuine Porsche Part - New (to order)
                          # 8
                          MPN: 90006711704
                          SOCKET HEAD BOLT M6X16
                          from £2.29
                          from £2.29
                          screw, cheese hd. - M 6 X 16 - D - MJ 1998>> Genuine Porsche Part - New In stock
                          # 9
                          -
                          BRACKET LEFT BRAKE HOSE SEE ILLUSTRATION: 604-010
                          # 9
                          -
                          BRACKET RIGHT BRAKE HOSE SEE ILLUSTRATION: 604-010
                          # 10
                          MPN: 99135180180
                          COVER PLATE WHEEL CARRIER
                          from £0.83
                          from £0.83
                          COVER PLATE Genuine Porsche Part - New (to order)
                          # 11
                          MPN: 99921711601
                          HEXAGON BOLT M6X16
                          HEXAGON BOLT M6X16
                          Supersession
                          Supersession
                          Genuine Porsche Part (no longer available to order)
                          # 11
                          MPN: PAF100829
                          HEXAGON HEAD BOLT (COMBI) M6X16 HEXAGON BOLT
                          from £0.61
                          from £0.61
                          This part replaces part number 99921711601 - and 1 more. Click to view details
                          BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New In stock
                          # 12
                          MPN: 99135160383
                          COVER PLATE LEFT
                          from £25.18
                          from £25.18
                          COVER PLATE Genuine Porsche Part - New (to order)
                          # 12
                          MPN: 99135160483
                          COVER PLATE RIGHT
                          from £25.18
                          from £25.18
                          COVER PLATE Genuine Porsche Part - New (to order)
                          # 13
                          MPN: 90037810801
                          HEXAGON BOLT AM8X35
                          from £2.29
                          from £2.29
                          screw, hex. hd. - AM 8 X 35 - D - MJ 2001>> Genuine Porsche Part - New (to order)
                          # 14
                          MPN: 9GT401111
                          OPERATING PIN CENTRAL LOCKING
                          from £7.74
                          from £7.74
                          OPERATING PIN Genuine Porsche Part - New (to order)
                          # 15
                          MPN: PAF009591
                          Torx M8X32 socket head bolt
                          from £1.00
                          from £1.00
                          TORX SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
