P450 (Ceramic brake (PCCB)) | PE1T (RS version)
porsche 2021 (718 cayman gt4) disc brake front axle parts diagram

602-030 - Disc Brake Front Axle

Porsche 2021 (718 Cayman GT4) Disc brake Front axle Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Key
                            Price
                            # 1
                            MPN: 9GT615301F
                            Brake disc left also use: 1x 9GT 615 302 F 1x 9GT 698 151 L
                            Brake disc left also use: 1x 9GT 615 302 F 1x 9GT 698 151 L
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 1
                            MPN: 9GT615301J
                            BRAKE DISC LEFT ALSO USE: 1X 9GT 615 302 J 1X 9GT 698 151 L
                            P450 (Ceramic brake (PCCB))
                            from £5,572.92
                            from £5,572.92
                            This part replaces part number 9GT615301F
                            BRAKE DISC Genuine Porsche Part - New (to order)
                            # 1
                            MPN: 9GT615302F
                            Brake disc right also use: 1x 9GT 615 301 F 1x 9GT 698 151 L
                            Brake disc right also use: 1x 9GT 615 301 F 1x 9GT 698 151 L
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 1
                            MPN: 9GT615302J
                            BRAKE DISC RIGHT ALSO USE: 1X 9GT 615 301 J 1X 9GT 698 151 L
                            P450 (Ceramic brake (PCCB))
                            from £5,684.38
                            from £5,684.38
                            This part replaces part number 99135140884 - and 1 more. Click to view details
                            BRAKE DISC Genuine Porsche Part - New (to order)
                            # 2
                            MPN: PAF009830
                            Hexagon socket head bolt, M6X8 self-locking
                            from £0.61
                            from £0.61
                            HEXAGON SOCKET HEAD BOLT, SELF-LOCKING Genuine Porsche Part - New (to order)
                            # 3
                            -
                            COVER PLATE LEFT WHEEL CARRIER SEE ILLUSTRATION: 401-050
                            # 3
                            -
                            COVER PLATE LEFT WHEEL CARRIER SEE ILLUSTRATION: 401-050
                            # 5
                            MPN: 9GT615123A
                            caliper without brake pads left yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            caliper without brake pads left yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            from £614.26
                            from £614.26
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - Used In stock
                            # 5
                            MPN: 9GT615123T
                            caliper without brake pads left yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            P1LQ
                            from £1,154.97
                            from £1,154.97
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9GT615124A
                            caliper without brake pads right yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            caliper without brake pads right yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            from £390.89
                            from £390.89
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - Damaged In stock
                            # 5
                            MPN: 9GT615124T
                            caliper without brake pads right yellow yellow also use: 2x WHT 008 186 1x 9P1 698 995 1x 9GT 698 151 AA
                            P1LQ
                            from £1,154.97
                            from £1,154.97
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 5
                            MPN: 9GT615123C
                            CALIPER WITHOUT BRAKE PADS LEFT BLACK BLACK ALSO USE: 2X WHT 008 186 1X 9P1 698 995 1X 9GT 698 151 AA 1X 9GT 907 637
                            P1LX
                            Supersession
                            Supersession
                            Genuine Porsche Part (no longer available to order)
                            # 5
                            MPN: 9GT615124C
                            CALIPER WITHOUT BRAKE PADS RIGHT BLACK BLACK ALSO USE: 2X WHT 008 186 1X 9P1 698 995 1X 9GT 698 151 AA 1X 9GT 907 637
                            P1LX
                            from £1,592.49
                            from £1,592.49
                            CALIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 9GT698151L
                            1 SET OF BRAKE PADS FOR DISK BRAKE
                            1 SET OF BRAKE PADS FOR DISK BRAKE
                            from £618.04
                            from £618.04
                            1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                            # 6
                            MPN: 9GT698151AA
                            1 SET OF BRAKE PADS FOR DISK BRAKE ALSO USE: 4X WHT 008 186 1X 9P1 698 995 1X 9GT 907 637 USE ONLY IN CONJUNCTION WITH: 1X 9GT 698 451 R
                            P450 (Ceramic brake (PCCB))
                            from £624.48
                            from £624.48
                            1 SET OF BRAKE PADS FOR DISK BRAKE Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 9P1615701A
                            CONNECTING LINE LEFT FIXED CALLIPER
                            from £26.70
                            from £26.70
                            connecting line Genuine Porsche Part - New (to order)
                            # 7
                            MPN: 9P1615702
                            CONNECTING LINE RIGHT FIXED CALLIPER
                            from £26.70
                            from £26.70
                            connecting line Genuine Porsche Part - New (to order)
                            # 8
                            MPN: WHT008186
                            Socket head bolt M12X1,5X62
                            from £17.29
                            from £17.29
                            This part replaces part number 99906705409
                            SCREW, CHEESE HD Genuine Porsche Part - New (to order)
                            # 9
                            MPN: 9P1698995
                            1 SET SPRINGS
                            from £29.18
                            from £29.18
                            1 SET OF SPRINGS Genuine Porsche Part - New (to order)
                            # 10
                            MPN: 9GT907637
                            SENDER WIRE (PAD WEAR INDICATOR)
                            from £31.87
                            from £31.87
                            This part replaces part number 99160918180
                            SENDER WIRE PAD WEAR INDICATOR Genuine Porsche Part - New (to order)
                            # 11
                            MPN: 9P1698671D
                            1 SET PROTECTIVE CAPS 30 MM CONTAINS: 6 PCS
                            from £13.50
                            from £13.50
                            1 set protective caps Genuine Porsche Part - New (to order)
                            # 12
                            MPN: 211611483
                            DUST CAP CONTAINS: 20 PC
                            from £3.60
                            from £3.60
                            dust cap - D >> - MJ 1983 Genuine Porsche Part - New (to order)
                            DUST CAP Genuine Lamborghini - New (to order)
                            # 13
                            MPN: 8A0615273
                            1 SET BLEEDER VALVES WITH FRONT DUST CAP WITH COVER CAP FIXED CALLIPER
                            from £9.05
                            from £9.05
                            BLEEDER VALVE Genuine Porsche Part - New (to order)
                            BLEEDER SCREW Genuine Lamborghini - New (to order)
                            # 14
                            MPN: 9P1615133A
                            CABLE HOLDER SENDER WIRE (PAD WEAR INDICATOR)
                            from £8.33
                            from £8.33
                            CABLE HOLDER Genuine Porsche Part - New (to order)
                            # 15
                            -
                            AIR DUCT FOR LEFT BRAKE COOLING SEE ILLUSTRATION: 801-800
                            # 16
                            -
                            AIR DUCT FOR LEFT BRAKE COOLING SEE ILLUSTRATION: 801-850
                            # 17
                            MPN: 00004330508
                            ASSEMBLY PASTE 100 GRAM
                            from £17.99
                            from £17.99
                            This part replaces part number 00004302000
                            ASSEMBLY PASTE Genuine Porsche Part - New (to order)
