107-067 - Intake manifold throttle valve adapter Air guide housing
Porsche 2016 (Macan) Intake manifold throttle valve adapter Air guide housing Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 95813320100
INTAKE MANIFOLD
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
Supersession
Supersession
# 1
MPN: PAC133201A
INTAKE MANIFOLD
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
# 2
MPN: 95812971700
SEAL
from £62.27
from £62.27
# 3
MPN: 95890738600
SWING ANGLE SENSOR
# 4
MPN: 95813307300
SEAL
from £18.59
from £18.59
# 5
MPN: 95813359500
HOSE
from £24.94
from £24.94
# 6
MPN: 95890628300
Change-over valve
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £36.77
from £36.77
# 7
MPN: 95813306200
THROTTLE VALVE ADAPTER
THROTTLE VALVE ADAPTER
from £569.15
from £569.15
# 7
MPN: 95813306210
THROTTLE VALVE ADAPTER
from £459.58
from £459.58
# 8
MPN: N 10626101
Hexagon socket flat TP6X45 head bolt
from £0.64
from £0.64
# 9
MPN: 95897149700
SUPPORT KNOCK SENSOR
from £4.80
from £4.80
# 10
MPN: N 90925202
HEXAGON SOCKET HEAD COLLARED 6X16 BOLT, THREAD FORMING
from £0.53
from £0.53
# 11
MPN: 95813358300
CONNECTING HOSE
# 12
MPN: 95813224100
CONNECTING HOSE
CONNECTING HOSE
# 12
MPN: 95813224110
CONNECTING HOSE
from £20.33
from £20.33
# 13
MPN: N 01508210
HEXAGON COLLAR NUT M6
from £0.47
from £0.47
# 14
MPN: N 91097301
Hexagon socket flat M6X45 head bolt
from £1.10
from £1.10
# 15
MPN: N 10770201
THREADED PIN M6FOX40
from £0.82
from £0.82
# 16
MPN: 95890605100
PRESSURE SENSOR
Supersession
Supersession
# 17
MPN: N 90732103
Hexagon socket oval head 4X16 bolt
from £0.47
from £0.47
# 18
MPN: 95812972300
SUPPORT INTAKE MANIFOLD
# 19
MPN: N 91170301
SOCKET HEAD COLLARED BOLT WITH M8X70 INNER MULTIPOINT HEAD
from £1.97
from £1.97
# 20
MPN: 95812127300
MOUNTING
from £8.72
from £8.72
# 21
MPN: N 10609202
HEXAGON COLLAR NUT M8
from £0.47
from £0.47
# 22
MPN: 95813368100
Fuel collection pipe Cylinders 1-4 only in conj. with: 958 127 813 00 M >>CNC 133 508
Fuel collection pipe Cylinders 1-4 only in conj. with: 958 127 813 00 M >>CNC 133 508
# 22
MPN: 95813368110
Fuel collection pipe Cylinders 1-4 only in conj. with: 958 127 813 10 M CNC 133 509>>
Fuel collection pipe Cylinders 1-4 only in conj. with: 958 127 813 10 M CNC 133 509>>
from £56.84
from £56.84
# 22
MPN: PAC133681
FUEL RAIL CYLINDERS 1-4 ONLY IN CONJ. WITH: 1X 958 127 813 10 1X N 910 568 01 M CNC 133 509>>
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £124.24
from £124.24
# 23
MPN: N 10582102
Hexagon socket flat M6X40 head bolt
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £0.84
from £0.84
# 24
MPN: 06H906051G
PRESSURE SENSOR
PRESSURE SENSOR
from £79.64
from £79.64
# 24
MPN: 06H906051J
PRESSURE SENSOR
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £34.12
from £34.12
# 24
MPN: PAC906051B
PRESSURE SENSOR
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £83.58
from £83.58
# 25
MPN: 95812781300
ADAPTER ONLY IN CONJ. WITH: 1X 958 133 681 00 1X
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018)
from £14.85
from £14.85
# 25
MPN: 95812781310
ADAPTER ONLY IN CONJ. WITH: 1X 958 133 681 10 1X PAC.133.681
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £2.84
from £2.84
# 26
MPN: WHT005568
O-RING 11X3,1 ONLY IN CONJ. WITH: 958 133 681 00 FUEL COLLECTION PIPE
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018)
from £2.62
from £2.62
# 26
MPN: N 91056801
O-RING 12X2 ONLY IN CONJ. WITH: 958 133 681 10 FUEL COLLECTION PIPE
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £2.16
from £2.16
# 27
MPN: 95813304700
Retaining Clip
Retaining Clip
from £0.76
from £0.76
# 27
MPN: PAC133047
Retaining Clip
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £0.94
from £0.94
# 28
MPN: 95890603100
INJECTION VALVE
INJECTION VALVE
from £86.58
from £86.58
# 28
MPN: PAC906031
INJECTION VALVE
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £156.98
from £156.98
# 29
MPN: 99970757440
O-RING 7,52X3,51 FOR INJECTION VALVE
from £6.77
from £6.77
# 30
MPN: 99970757340
O-RING 8,3X3,05 FOR INJECTION VALVE
from £5.17
from £5.17
# 31
MPN: 95890303700
Retaining Clip
CNCC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNCC and installed 05/2014-09/2018) | CNC (2.0 Litre 4 Cyliner Engine (236 Horsepower / 174 Kilowatt with Engine Code: CNC and installed 05/2014-09/2018) | CYPA (2.0 Litre 4 Cyliner Engine (252 Horsepower / 185 Kilowatt with Engine Code: CYPA and installed 05/2015-09/2018) | CYP (2.0 Litre 4 Cyliner Engine (251 Horsepower / 185 Kilowatt with Engine Code: CYP and installed 05/2017-09/2018)
from £2.13
from £2.13
# 32
MPN: WHT005593
BALL PIN TP6X13.7
from £1.54
from £1.54
# 33
-
FUEL HOSE SEE ILLUSTRATION, ITEM: 107-050,26
# 34
-
INTAKE MANIFOLD SEE ILLUSTRATION, ITEM: 106-020,5
