PTV8 (6-cylinder SI engine 2.9 l unit 06M.A) with GP2
porsche 2020 (macan) oil pump parts diagram

104-005 - oil pump

Porsche 2020 (Macan) oil pump Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: PAB115103
                      oil pump
                      from £354.02
                      from £354.02
                      oil pump Genuine Porsche Part - New (to order)
                      # 2
                      MPN: 9A711512110
                      CHAIN SPROCKET
                      from £53.74
                      from £53.74
                      SPROCKET Genuine Porsche Part - New (to order)
                      # 3
                      MPN: 9A700806100
                      Oval-head screw M8X22
                      from £11.00
                      from £11.00
                      OVAL-HEAD SCREW Genuine Porsche Part - New (to order)
                      # 4
                      MPN: 9A710316110
                      SEAL FOR OIL PUMP
                      from £11.80
                      from £11.80
                      SEAL FOR OIL PUMP Genuine Porsche Part - New (to order)
                      # 5
                      MPN: N 10562602
                      ROUND HD. SCREW M6X60
                      from £0.95
                      from £0.95
                      ROUND HD. SCREW Genuine Porsche Part - New (to order)
                      # 6
                      -
                      TIMING CHAIN SEE ILLUSTRATION: 103-150
                      # 7
                      MPN: PAB11515510
                      INTAKE MANIFOLD OIL PUMP
                      INTAKE MANIFOLD OIL PUMP
                      Supersession
                      Supersession
                      Genuine Porsche Part (no longer available to order)
                      # 7
                      MPN: PAB115155B
                      INTAKE MANIFOLD OIL PUMP
                      from £31.00
                      from £31.00
                      This part replaces part number PAB11515510
                      INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                      # 8
                      MPN: N 91069701
                      O-RING 26X2,5
                      from £2.66
                      from £2.66
                      O-RING Genuine Porsche Part - New (to order)
                      O-RING Genuine Lamborghini - New In stock
                      # 9
                      MPN: PAB115393
                      CONTROL VALVE OIL PUMP
                      from £88.37
                      from £88.37
                      CONTROL VALVE Genuine Porsche Part - New (to order)
                      # 10
                      MPN: 9A711547500
                      O-RING 14X2
                      from £3.55
                      from £3.55
                      O-RING Genuine Porsche Part - New (to order)
                      # 11
                      MPN: N 10196103
                      Oval socket head bolt M6X18 with hex drive
                      from £0.78
                      from £0.78
                      oval socket head bolt Genuine Porsche Part - New In stock
                      HEXALOBULAR SOCKET M6X18 Genuine Lamborghini - New In stock
