PT9I (6-cylinder SI engine 3.0 l unit 06M.C) | P0P8 (Exhaust system (exhaust sound)) | P0P9 (Rear tailpipe)
porsche 2020 (macan) exhaust system front silencer rear silencer parts diagram

202-360 - exhaust system Front silencer Rear silencer

Porsche 2020 (Macan) exhaust system Front silencer Rear silencer Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Key
                              Price
                              # 1
                              MPN: 95B253487MY
                              EXHAUST PIPE
                              from £564.29
                              from £564.29
                              EXHAUST PIPE Genuine Porsche Part - New (to order)
                              # 2
                              MPN: 8K0253144F
                              BRACKET
                              from £20.57
                              from £20.57
                              BRACKET Genuine Porsche Part - New (to order)
                              # 3
                              MPN: 8K0253144E
                              BRACKET
                              from £20.50
                              from £20.50
                              BRACKET Genuine Porsche Part - New (to order)
                              # 4
                              MPN: N 91130802
                              Hexagon collar nut M8 self-locking
                              Hexagon collar nut M8 self-locking
                              from £1.79
                              from £1.79
                              Genuine Porsche Part (no longer available to order)
                              PREV.TORQUE TYPE Genuine Lamborghini - New (to order)
                              # 4
                              MPN: PAF911308
                              Hexagon collar nut M8 self-locking
                              from £1.90
                              from £1.90
                              This part replaces part number N 91130802
                              HEXAGON COLLAR NUT SELF-LOCKING Genuine Porsche Part - New (to order)
                              # 5
                              MPN: N 02300316
                              HEXAGON NUT M8
                              from £0.47
                              from £0.47
                              HEX. NUT Genuine Porsche Part - New (to order)
                              PREV.TORQUE TYPE Genuine Lamborghini - New (to order)
                              # 6
                              MPN: 95811122010
                              CLAMPING SLEEVE 65X88MM
                              CLAMPING SLEEVE 65X88MM
                              Supersession
                              Supersession
                              Genuine Porsche Part (no longer available to order)
                              # 6
                              MPN: PAB111220A
                              CLAMPING SLEEVE 65X88MM EXHAUST SYSTEM
                              from £27.87
                              from £27.87
                              This part replaces part number 95811122010
                              CLAMPING SLEEVE Genuine Porsche Part - New (to order)
                              # 7
                              MPN: 95811122010
                              CLAMPING SLEEVE 65X88MM
                              CLAMPING SLEEVE 65X88MM
                              Supersession
                              Supersession
                              Genuine Porsche Part (no longer available to order)
                              # 7
                              MPN: PAB111220A
                              CLAMPING SLEEVE 65X88MM
                              from £27.87
                              from £27.87
                              This part replaces part number 95811122010
                              CLAMPING SLEEVE Genuine Porsche Part - New (to order)
                              # 8
                              MPN: 95B253611MY
                              REAR SILENCER LEFT
                              from £821.42
                              from £821.42
                              EXHAUST SILENCER, REAR Genuine Porsche Part - New (to order)
                              # 9
                              MPN: 9A713324606
                              SERVOMOTOR FOR EXHAUST FLAP
                              SERVOMOTOR FOR EXHAUST FLAP
                              Supersession
                              Supersession
                              Genuine Porsche Part (no longer available to order)
                              # 9
                              MPN: 9A7133246A
                              SERVOMOTOR FOR EXHAUST FLAP
                              from £211.77
                              from £211.77
                              This part replaces part number 9A713324606
                              SERVOMOTOR FOR EXHAUST FLAP Genuine Porsche Part - New (to order)
                              # 10
                              MPN: N 10597201
                              Hexagon collar nut M5 self-locking
                              from £1.10
                              from £1.10
                              SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
                              HEXAGON COLLAR NUT M5 Genuine Lamborghini - New (to order)
                              # 11
                              MPN: 4H0253233
                              GUARD PLATE SERVOMOTOR
                              from £18.87
                              from £18.87
                              SHIELD Genuine Porsche Part - New (to order)
                              # 12
                              MPN: 95B253144
                              RETAINER FOR EXHAUST SYSTEM
                              from £23.46
                              from £23.46
                              BRACKET FOR EXHAUST SYSTEM Genuine Porsche Part - New (to order)
                              # 13
                              MPN: 95B253612MY
                              REAR SILENCER RIGHT
                              from £821.42
                              from £821.42
                              EXHAUST SILENCER, REAR Genuine Porsche Part - New (to order)
                              # 14
                              MPN: 9A713324606
                              SERVOMOTOR FOR EXHAUST FLAP
                              SERVOMOTOR FOR EXHAUST FLAP
                              Supersession
                              Supersession
                              Genuine Porsche Part (no longer available to order)
                              # 14
                              MPN: 9A7133246A
                              SERVOMOTOR FOR EXHAUST FLAP
                              from £211.77
                              from £211.77
                              This part replaces part number 9A713324606
                              SERVOMOTOR FOR EXHAUST FLAP Genuine Porsche Part - New (to order)
                              # 15
                              MPN: N 10597201
                              Hexagon collar nut M5 self-locking
                              from £1.10
                              from £1.10
                              SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
                              HEXAGON COLLAR NUT M5 Genuine Lamborghini - New (to order)
                              # 16
                              MPN: 4H0253233
                              GUARD PLATE SERVOMOTOR
                              from £18.87
                              from £18.87
                              SHIELD Genuine Porsche Part - New (to order)
                              # 17
                              MPN: 95B253144A
                              RETAINER FOR EXHAUST SYSTEM RIGHT
                              from £23.46
                              from £23.46
                              BRACKET FOR EXHAUST SYSTEM Genuine Porsche Part - New (to order)
                              # 18
                              MPN: N 10662001
                              Hex collared bolt M8X40
                              from £1.00
                              from £1.00
                              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95B253681AL
                              TAILPIPE LEFT OUTER
                              TAILPIPE LEFT OUTER
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95B253681CP
                              TAILPIPE LEFT OUTER
                              P0P8 (Exhaust system (exhaust sound))
                              from £300.59
                              from £300.59
                              This part replaces part number 95B253681P
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95B253681AT
                              TAILPIPE LEFT OUTER
                              TAILPIPE LEFT OUTER
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95B253681R
                              TAILPIPE LEFT OUTER
                              TAILPIPE LEFT OUTER
                              from £317.52
                              from £317.52
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 19
                              MPN: 95B253681CR
                              TAILPIPE LEFT OUTER
                              P0P9 (Rear tailpipe)
                              from £300.59
                              from £300.59
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 20
                              MPN: 95B253681AM
                              TAILPIPE LEFT INNER
                              P0P8 (Exhaust system (exhaust sound))
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 20
                              MPN: 95B253681AS
                              TAILPIPE LEFT INNER
                              P0P9 (Rear tailpipe)
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 21
                              MPN: 95B253682AL
                              TAILPIPE RIGHT OUTER
                              P0P8 (Exhaust system (exhaust sound))
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 21
                              MPN: 95B253682AT
                              TAILPIPE RIGHT OUTER
                              P0P9 (Rear tailpipe)
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 22
                              MPN: 95B253682AM
                              TAILPIPE RIGHT INNER
                              P0P8 (Exhaust system (exhaust sound))
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 22
                              MPN: 95B253682AS
                              TAILPIPE RIGHT INNER
                              P0P9 (Rear tailpipe)
                              TAILPIPE Genuine Porsche Part - New (to order)
                              # 23
                              MPN: 9A700801900
                              flat round head bolt M6X12
                              from £1.23
                              from £1.23
                              SCREW, ROUND HD Genuine Porsche Part - New In stock
