PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
porsche 2020 (macan) mounting parts for engine and transmission parts diagram

306-015 - mounting parts for engine and transmission

Porsche 2020 (Macan) mounting parts for engine and transmission Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: N 91129101
                        dodecagonal head bolt M10X40
                        from £2.60
                        from £2.60
                        12-point SOCKET SHOULDER SCREW Genuine Porsche Part - New (to order)
                        12-POINT FLANGE M10X40 Genuine Lamborghini - New (to order)
                        # 2
                        MPN: 0B5301433
                        SECURING RING
                        from £2.09
                        from £2.09
                        LOCK RING Genuine Porsche Part - New (to order)
                        PISTON RETAINING Genuine Lamborghini - New In stock
                        # 3
                        MPN: N 91129401
                        12-POINT HEAD BOLT M12X50
                        from £3.18
                        from £3.18
                        12 POINT SOCKET HEAD SCREW Genuine Porsche Part - New (to order)
                        12-POINT FLANGE BOLT Genuine Lamborghini - New (to order)
                        # 4
                        MPN: PAF911295
                        12-EDGE FLANGE SCREW M12X75
                        from £4.09
                        from £4.09
                        This part replaces part number N 91129501
                        12-EDGE FLANGE SCREW Genuine Porsche Part - New (to order)
                        # 5
                        MPN: PAF911296
                        12-POINT head bolt M12X100X90
                        from £4.83
                        from £4.83
                        12-POINT HEAD BOLT Genuine Porsche Part - New (to order)
                        # 6
                        MPN: N 91129701
                        12-POINT HEAD BOLT M12X120
                        from £4.63
                        from £4.63
                        12 POINT SOCKET HEAD SCREW Genuine Porsche Part - New (to order)
                        # 7
                        MPN: N 10314506
                        Hex collared bolt M10X50
                        from £2.94
                        from £2.94
                        BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                        HEXAGON FLANGE AM10X50 Genuine Lamborghini - New (to order)
                        # 8
                        MPN: 8K0145198
                        SPACER SLEEVE
                        from £14.59
                        from £14.59
                        SPACER SLEEVE Genuine Porsche Part - New (to order)
                        # 9
                        MPN: 8K0301257A
                        TRANSMISSION HOUSING COVER
                        from £2.08
                        from £2.08
                        COVER FOR TRANSMISSION CASE Genuine Porsche Part - New (to order)
                        COVER F. MLB + MLBEVO Genuine Lamborghini - New (to order)
                        COVER F. MLB + MLBEVO Genuine Lamborghini - Used In stock
                        # 10
                        MPN: PAF911432
                        12-POINT head bolt M10X1X15,5
                        from £3.33
                        from £3.33
                        This part replaces part number N 91143203
                        12-POINT HEAD BOLT Genuine Porsche Part - New (to order)
                        # 11
                        MPN: 06H103565
                        COVER
                        from £10.04
                        from £10.04
                        COVER Genuine Porsche Part - New (to order)
