PE0W (Special edition) | P1BH (Suspension/shock absorption, standard 2) | P0JG (Weight category front axle weight range 7) | P0JH (Weight category front axle weight range 8) | P0JJ (Weight category front axle weight range 9) | P0JK (Weight category front axle weight range 10) | P0JL (Weight category front axle weight range 11)
porsche 2020 (macan) steel spring suspension parts diagram

402-006 - steel spring suspension

Porsche 2020 (Macan) Steel spring suspension Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                    #
                                                    Part number
                                                    Description
                                                    Key
                                                    Price
                                                    # 1
                                                    MPN: 95B411105BA504
                                                    COIL SPRING - 1 PAIR OF SPRINGS COLOUR DESIGNATION: SILVER YELLOW
                                                    P0JJ (Weight category front axle weight range 9)
                                                    from £263.46
                                                    from £263.46
                                                    This part replaces part number 95B411105BA
                                                    1 PAIR OF SPRINGS Genuine Porsche Part - New (to order)
                                                    # 1
                                                    MPN: 95B411105BB504
                                                    COIL SPRING - 1 PAIR OF SPRINGS COLOUR DESIGNATION: SILVER BLUE
                                                    P0JK (Weight category front axle weight range 10)
                                                    from £263.46
                                                    from £263.46
                                                    This part replaces part number 95B411105BB
                                                    1 PAIR OF SPRINGS Genuine Porsche Part - New (to order)
                                                    # 1
                                                    MPN: 95B411105BC504
                                                    COIL SPRING - 1 PAIR OF SPRINGS COLOUR DESIGNATION: GREY VIOLET
                                                    P0JL (Weight category front axle weight range 11)
                                                    from £263.46
                                                    from £263.46
                                                    This part replaces part number 95B411105BC
                                                    1 PAIR OF SPRINGS Genuine Porsche Part - New (to order)
                                                    # 1
                                                    MPN: 95B411105BD504
                                                    COIL SPRING - 1 PAIR OF SPRINGS COLOUR DESIGNATION: GREY GREEN
                                                    P0JG (Weight category front axle weight range 7) | P0JH (Weight category front axle weight range 8)
                                                    from £263.46
                                                    from £263.46
                                                    COIL SPRING 1 PAIR OF SPRINGS Genuine Porsche Part - New (to order)
                                                    # 2
                                                    MPN: 8K0412103C
                                                    SPRING DISC LOWER
                                                    from £14.22
                                                    from £14.22
                                                    SPRING SEAT Genuine Porsche Part - New (to order)
                                                    # 3
                                                    MPN: 8K0412109A
                                                    UNDERLAY
                                                    from £16.27
                                                    from £16.27
                                                    PACKING Genuine Porsche Part - New (to order)
                                                    # 4
                                                    MPN: 95B412127
                                                    PROTECTIVE CAP
                                                    from £9.14
                                                    from £9.14
                                                    PROTECTIVE CAP Genuine Porsche Part - New (to order)
                                                    # 5
                                                    MPN: 95B412137
                                                    PROTECTIVE SLEEVE
                                                    from £9.23
                                                    from £9.23
                                                    BOOT Genuine Porsche Part - New (to order)
                                                    # 6
                                                    MPN: 95B412131E
                                                    STOP BUFFER
                                                    from £20.06
                                                    from £20.06
                                                    JOUNCE BUMPER Genuine Porsche Part - New (to order)
                                                    # 7
                                                    MPN: WHT001484
                                                    WASHER
                                                    from £0.47
                                                    from £0.47
                                                    WASHER Genuine Porsche Part - New (to order)
                                                    # 8
                                                    MPN: 95B412109
                                                    BEARING PLATE
                                                    from £25.18
                                                    from £25.18
                                                    CONCAVE SUPPORT Genuine Porsche Part - New (to order)
                                                    # 9
                                                    MPN: 95B411178
                                                    INSERT
                                                    from £40.74
                                                    from £40.74
                                                    PACKING Genuine Porsche Part - New (to order)
                                                    # 10
                                                    MPN: 95B412321B
                                                    BEARING PLATE INCLUDED SHOCK ABSORBER BEARING
                                                    from £181.23
                                                    from £181.23
                                                    CONCAVE SUPPORT Genuine Porsche Part - New (to order)
                                                    # 11
                                                    MPN: 99908445801
                                                    HEXAGON NUT M12X1,5
                                                    from £1.08
                                                    from £1.08
                                                    HEX. NUT Genuine Porsche Part - New (to order)
                                                    # 12
                                                    MPN: 1J0973802
                                                    FLAT CONNECTOR HOUSING WITH CONTACT LOCKING MECHANISM
                                                    from £4.70
                                                    from £4.70
                                                    FLAT CONNECTOR HOUSING WITH Genuine Porsche Part - New (to order)
                                                    TAB CONNECTOR Genuine Lamborghini - New (to order)
                                                    # 13
                                                    MPN: 1J0906102
                                                    GROMMET
                                                    from £1.37
                                                    from £1.37
                                                    GROMMET Genuine Porsche Part - New (to order)
                                                    GROMMET Genuine Lamborghini - New (to order)
                                                    # 14
                                                    MPN: 95B972869
                                                    CABLE GUIDE
                                                    from £2.32
                                                    from £2.32
                                                    WIRING CONDUIT Genuine Porsche Part - New (to order)
                                                    # 15
                                                    MPN: 95B412383
                                                    BRACKET LEFT
                                                    from £130.11
                                                    from £130.11
                                                    BRACKET Genuine Porsche Part - New (to order)
                                                    # 15
                                                    MPN: 95B412384
                                                    BRACKET RIGHT
                                                    from £130.11
                                                    from £130.11
                                                    BRACKET Genuine Porsche Part - New (to order)
                                                    # 16
                                                    MPN: 95B412081A
                                                    SEAL RING
                                                    from £42.03
                                                    from £42.03
                                                    SEAL RING Genuine Porsche Part - New (to order)
                                                    # 17
                                                    MPN: 99908465701
                                                    HEXAGON NUT M8
                                                    from £0.82
                                                    from £0.82
                                                    HEX. NUT Genuine Porsche Part - New (to order)
                                                    # 18
                                                    MPN: 95B413031R
                                                    SUSPENSION STRUT, COMPLETE
                                                    from £588.55
                                                    from £588.55
                                                    SUSPENSION STRUT, COMPLETE Genuine Porsche Part - New (to order)
                                                    # 19
                                                    MPN: 95B413037C
                                                    SUSPENSION FORKS LEFT
                                                    from £265.98
                                                    from £265.98
                                                    SUSPENSION FORK Genuine Porsche Part - New (to order)
                                                    # 19
                                                    MPN: 95B413038C
                                                    SUSPENSION FORKS RIGHT
                                                    from £265.98
                                                    from £265.98
                                                    SUSPENSION FORK Genuine Porsche Part - New (to order)
                                                    # 20
                                                    MPN: PAF104029
                                                    Hexagon collar nut M12X1.5
                                                    from £3.03
                                                    from £3.03
                                                    This part replaces part number N 10402904
                                                    HEXAGON COLLAR NUT Genuine Porsche Part - New In stock
                                                    # 21
                                                    MPN: N 10628301
                                                    HEX COLLARED BOLT M12X1.5X90
                                                    from £3.35
                                                    from £3.35
                                                    BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                                    HEXAGON FLANGE BOLT Genuine Lamborghini - New (to order)
                                                    # 23
                                                    MPN: 95B907508A
                                                    ACCELERATOR SENSOR
                                                    from £111.50
                                                    from £111.50
                                                    ACCELERATOR SENSOR Genuine Porsche Part - New (to order)
                                                    # 24
                                                    MPN: N 10196103
                                                    Oval socket head bolt M6X18 with hex drive
                                                    from £0.78
                                                    from £0.78
                                                    oval socket head bolt Genuine Porsche Part - New In stock
                                                    HEXALOBULAR SOCKET M6X18 Genuine Lamborghini - New In stock
                                                    # 25
                                                    MPN: N 91066101
                                                    HEXAGON HEAD BOLT (COMBI) M10X35
                                                    from £2.86
                                                    from £2.86
                                                    BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                                                    # 26
                                                    MPN: N 10106402
                                                    HEXAGON COLLAR NUT M12X1,5 SELF-LOCKING
                                                    from £1.28
                                                    from £1.28
                                                    SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
                                                    PREV.TORQUE TYPE M12X1.5 Genuine Lamborghini - New In stock
                                                    # 27
                                                    MPN: N 10421304
                                                    HEXAGON HEAD BOLT (COMBI) M12X1,5X80 BOLT WITH WASHER
                                                    from £5.17
                                                    from £5.17
                                                    BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New In stock
