PE0A (No special edition) | PE0E (Original) | P1BA (Standard suspension/shock absorption) | P1BH (Suspension/shock absorption, standard 2) | P1BK (4-corner air suspension with electronic shock absorption control) | PT2B (4-cylinder SI engine 2.0 l unit 06N.B 888evo4)
porsche 2020 (macan) anti-roll bar parts diagram

502-040 - ANTI-ROLL BAR

Porsche 2020 (Macan) Anti-roll bar Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 95B511305H
              ANTI-ROLL BAR ALSO USE: 4X N 106 957 01 4X N 912 289 01 2X N 102 723 02 USE IF REQUIRED: 2X 95B 511 439 2X 95B 511 035
              P1BA (Standard suspension/shock absorption) | P1BH (Suspension/shock absorption, standard 2)
              from £140.75
              from £140.75
              ANTI-ROLL BAR Genuine Porsche Part - New (to order)
              # 1
              MPN: 95B511305H
              ANTI-ROLL BAR ALSO USE: 4X N 106 957 01 4X N 912 289 01 2X N 102 723 02 USE IF REQUIRED: 2X 95B 511 439 2X 95B 511 035
              P1BK (4-corner air suspension with electronic shock absorption control) | PE0A (No special edition)
              from £140.75
              from £140.75
              ANTI-ROLL BAR Genuine Porsche Part - New (to order)
              # 1
              MPN: 95B511305J
              ANTI-ROLL BAR ALSO USE: 4X N 106 957 01 4X N 912 289 01 2X N 102 723 02 USE IF REQUIRED: 2X 95B 511 439 2X 95B 511 035
              P1BK (4-corner air suspension with electronic shock absorption control) | PE0E (Original)
              from £147.25
              from £147.25
              ANTI-ROLL BAR Genuine Porsche Part - New (to order)
              # 2
              MPN: 95B511035
              anti-roll bar bearing bracket also use: 2X N 106 957 01 use if required: 1X 95B 511 439
              from £17.98
              from £17.98
              MOUNT FOR STABILIZER Genuine Porsche Part - New (to order)
              # 3
              MPN: 95B511439
              Clamp also use: 2X N 106 957 01 use if required: 1X 95B 511 035
              from £22.37
              from £22.37
              CLAMP Genuine Porsche Part - New (to order)
              # 4
              MPN: N 10695701
              Hex collared bolt M8X65
              from £1.73
              from £1.73
              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
              # 5
              MPN: 95B505465
              Coupling rod also use: 2X N 912 289 01 1X N 102 723 02
              from £74.74
              from £74.74
              CONNECTING LINK Genuine Porsche Part - New (to order)
              # 6
              MPN: N 10272302
              Hexagon collar nut M10 self-locking
              from £1.28
              from £1.28
              SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
              PREV.TORQUE TYPE M10 Genuine Lamborghini - New In stock
              # 7
              MPN: N 91228901
              HEXAGON HEAD BOLT (COMBI) M10X70-S1
              from £2.43
              from £2.43
              BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
              HEXAGON HEAD BOLT M10X70-S1 Genuine Lamborghini - New (to order)
              # 8
              MPN: 95B907324A
              BRACKET ADAPTER CONTROL UNIT TYRE PRESSURE CONTROL SYSTEM
              P7K3 (Tire pressure monitoring system 433 MHz High) | P7K4 (Tire pressure monitoring system 315 MHz High)
              from £7.87
              from £7.87
              BRACKET Genuine Porsche Part - New (to order)
