porsche 2020 (macan) electrics control units standard seat parts diagram

817-505 - Electrics Control units Standard seat

Porsche 2020 (Macan) Electrics Control units Standard seat Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: 95861876004
Control Unit Seat
P3L4 (Power seats in front, driver seat with memory feature) | P3L6 (Power seats in front, driver seat with memory feature) | P3PN (Power seat adjustment for both front seats with memory feature)
from £342.12
from £342.12
electronic control module Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363FG
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
from £34.13
from £34.13
LOOM Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363FJ
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
from £42.65
from £42.65
LOOM Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363FD
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
PL0L (Left-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger) | P4UQ (Airbag for driver and front passenger)
from £79.03
from £79.03
LOOM Genuine Porsche Part - New (to order)
# 2
MPN: 95B 971 363 EA
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363EC
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
PL0L (Left-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L5 (Both front seats power-adjustable ) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger) | P4UQ (Airbag for driver and front passenger)
from £72.06
from £72.06
LOOM Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363EE
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
PL0R (Right-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L5 (Both front seats power-adjustable ) | P3L6 (Power seats in front, driver seat with memory feature) | P4A0 (Without seat heater) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger) | P4UQ (Airbag for driver and front passenger)
from £34.13
from £34.13
LOOM Genuine Porsche Part - New (to order)
# 2
MPN: 95B971363EF
WIRING HARNESS FOR LEFT ELECTRICALLY ADJUSTABLE SEAT
PL0R (Right-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L5 (Both front seats power-adjustable ) | P3L6 (Power seats in front, driver seat with memory feature) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger)
from £72.06
from £72.06
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B 971 364 EC
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364EE
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
PL0L (Left-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P3L5 (Both front seats power-adjustable ) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger)
from £50.82
from £50.82
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B 971 364 ED
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364EF
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
PL0L (Left-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P3L5 (Both front seats power-adjustable ) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4UQ (Airbag for driver and front passenger)
from £85.51
from £85.51
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364FG
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
from £34.13
from £34.13
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364FH
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
from £42.65
from £42.65
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364FD
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
PL0R (Right-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L6 (Power seats in front, driver seat with memory feature) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4D0 (Without seat ventilation/massage seat) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger)
from £79.03
from £79.03
LOOM Genuine Porsche Part - New (to order)
# 3
MPN: 95B971364EE
WIRING HARNESS FOR RIGHT ELECTRICALLY ADJUSTABLE SEAT
PL0R (Right-hand drive) | PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L5 (Both front seats power-adjustable ) | P4A0 (Without seat heater) | P4A3 (Seat heater for front seats separately controlled) | P4A4 (Seat heater for front and rear seats separately controlled) | P4UD (Airbag for driver and front passenger) | P4UE (Airbag for driver and front passenger)
from £50.82
from £50.82
LOOM Genuine Porsche Part - New (to order)
# 4
MPN: 7P5971384P
WIRING HARNESS FOR BACKREST ADJUSTMENT
PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P3L5 (Both front seats power-adjustable ) | P3L6 (Power seats in front, driver seat with memory feature)
from £73.68
from £73.68
HARNESS FOR BACKREST Genuine Porsche Part - New (to order)
# 5
MPN: 9A7959747 L0H
SWITCH MODULE FOR SEAT LEFT FRONT SEAT ADJUSTER - GALVANO SILVER
PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L5 (Both front seats power-adjustable ) | P3L6 (Power seats in front, driver seat with memory feature)
from £464.40
from £464.40
SWITCH MODULE FOR SEAT GALVANO SILVER Genuine Porsche Part - New (to order)
# 5
MPN: 9A7959747A L0H
SWITCH MODULE FOR SEAT LEFT FRONT SEAT ADJUSTER - GALVANO SILVER
PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P3PN (Power seat adjustment for both front seats with memory feature)
from £464.40
from £464.40
SWITCH MODULE FOR SEAT GALVANO SILVER Genuine Porsche Part - New (to order)
# 6
MPN: 9A7959748A L0H
SWITCH MODULE FOR SEAT RIGHT FRONT SEAT ADJUSTER - GALVANO SILVER
PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L6 (Power seats in front, driver seat with memory feature) | P3PN (Power seat adjustment for both front seats with memory feature)
from £464.40
from £464.40
SWITCH MODULE FOR SEAT GALVANO SILVER Genuine Porsche Part - New (to order)
# 6
MPN: 9A7959748 L0H
SWITCH MODULE FOR SEAT RIGHT FRONT SEAT ADJUSTER - GALVANO SILVER
PQ1G (Standard seats in front) | PQ4P (Sports front seats) | P3L4 (Power seats in front, driver seat with memory feature) | P3L5 (Both front seats power-adjustable )
from £464.40
from £464.40
SWITCH MODULE FOR SEAT GALVANO SILVER Genuine Porsche Part - New (to order)
# 7
MPN: 95861855302
INLAY FOR SEAT OCCUPIED SENSOR
P9P6 (Seat belt reminder, electric contact in buckle)
from £44.48
from £44.48
CONTACT STRIP FOR Genuine Porsche Part - New (to order)
