P1BK (4-corner air suspension with electronic shock absorption control) | PL0L (Left-hand drive) | PL0R (Right-hand drive)
porsche 2025 (macan-e) adaptive suspension air supply parts diagram

502-150 - Adaptive suspension Air supply

Porsche 2025 (Macan-E) Adaptive suspension Air supply Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: PAC616653
            PRESSURE LINE FRONT LEFT RED
            PL0L (Left-hand drive)
            from £32.19
            from £32.19
            PRESSURE LINE Genuine Porsche Part - New (to order)
            # 1
            MPN: PAC616653A
            PRESSURE LINE FRONT LEFT RED
            PL0R (Right-hand drive)
            from £32.19
            from £32.19
            PRESSURE LINE Genuine Porsche Part - New (to order)
            # 2
            MPN: PAC616654
            PRESSURE LINE FRONT RIGHT GREEN
            PL0L (Left-hand drive)
            from £32.19
            from £32.19
            PRESSURE LINE Genuine Porsche Part - New (to order)
            # 2
            MPN: PAC616654A
            PRESSURE LINE FRONT RIGHT GREEN
            PL0R (Right-hand drive)
            from £32.19
            from £32.19
            PRESSURE LINE Genuine Porsche Part - New (to order)
            # 3
            MPN: PAC 616 673
            PRESSURE LINE REAR LEFT BLACK
            PRESSURE LINE REAR LEFT BLACK Genuine Porsche Part - New (to order)
            # 4
            MPN: PAC 616 674
            Pressure line rear right blue
            Pressure line rear right blue Genuine Porsche Part - New (to order)
            # 5
            MPN: PAF108992
            COMBINATION HOLDER A07-4/4XC13- 8X13
            from £2.59
            from £2.59
            COMBINATION HOLDER Genuine Porsche Part - New (to order)
            # 6
            MPN: PAF108990
            COMBINATION HOLDER A01-4XC13-8X13
            from £2.24
            from £2.24
            COMBINATION HOLDER Genuine Porsche Part - New (to order)
            # 7
            MPN: 9J1616640
            REPAIR SET FOR AIR 4X0,85 CHANNEL
            from £88.96
            from £88.96
            REPAIR SET FOR AIR CHANNEL Genuine Porsche Part - New (to order)
