Rear axle. D - MJ 2014>> (TURBO TURBO S CWBA,CWB, CWCA,C)
porsche 2015 (panamera 970) disc brakes parts diagram

603-007 - disc brakes

Porsche 2015 (Panamera 970) DISC BRAKES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 298615601B
            BRAKE DISC
            left rear |
            also use: 1x 298615602B | 1x 97035294905 (PR:-450,-016)
            from £205.06
            from £205.06
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 1
            MPN: 298615602B
            BRAKE DISC
            right rear |
            also use: 1x 298615601B | 1x 97035294905 (PR:-450,-016)
            from £205.06
            from £205.06
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 1
            MPN: 298615601
            BRAKE DISC
            left rear |
            also use: 1x 298615602 | 1x 99135294803 | Discontinued part (PR:450,-016)
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 1
            MPN: 298615601C
            BRAKE DISC
            left rear |
            also use: 1x 298615602C | 1x 99135294803 (PR:450)
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 1
            MPN: 298615602
            BRAKE DISC
            right rear |
            also use: 1x 298615601 | 1x 99135294803 | Discontinued part (PR:450,-016)
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 1
            MPN: 298615602C
            BRAKE DISC
            right rear |
            also use: 1x 298615601C | 1x 99135294803 (PR:450)
            BRAKE DISC Genuine Porsche Part - New (to order)
            # 2
            MPN: 90026904703
            SCREW, CSK. HD.
            M 6 X 12
            from £0.50
            from £0.50
            SCREW, COUNTERSUNK HD Genuine Porsche Part - New (to order)
            # 3
            MPN: 97035280101
            COVER PLATE
            LEFT
            from £22.16
            from £22.16
            COVER PLATE Genuine Porsche Part - New (to order)
            # 3
            MPN: 97035280201
            COVER PLATE
            RIGHT
            from £22.16
            from £22.16
            COVER PLATE Genuine Porsche Part - New (to order)
            # 3
            MPN: 97035280533
            COVER PLATE
            LEFT
            from £131.96
            from £131.96
            COVER PLATE Genuine Porsche Part - New (to order)
            # 3
            MPN: 97035280633
            COVER PLATE
            right (PR:450)
            from £131.96
            from £131.96
            COVER PLATE Genuine Porsche Part - New (to order)
            # 4
            MPN: 99921711601
            SCREW, HEX. HD.
            M 6 X 16
            from £0.71
            from £0.71
            SCREW, HEX. HD Genuine Porsche Part - New (to order)
            # 5
            MPN: 00004311039
            REPAIR SET FOR
            rear axle | Fixed calliper | red | comprising: | Fixed calliper 1x left | Fixed calliper 1x right |
            F >> 97-EL080 184 (PR:-450)
            from £614.50
            from £614.50
            REPAIR SET FOR Genuine Porsche Part - New (to order)
            # 5
            MPN: 298615149B
            FIXED CALLIPER
            left | red | F 97-EL080 185>> (PR:-450)
            FIXED CALLIPER Genuine Porsche Part - New (to order)
            # 5
            MPN: 00004311040
            REPAIR SET FOR
            rear axle | Fixed calliper | yellow | comprising: | Fixed calliper 1x left | Fixed calliper 1x right |
            F >> 97-EL070 482 (PR:450)
            from £682.75
            from £682.75
            REPAIR SET FOR Genuine Porsche Part - New (to order)
            # 5
            MPN: 97035242534
            CALLIPER WITHOUT BRAKE PADS
            left | yellow | F 97-EL070 483>> (PR:450)
            CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
            # 5
            MPN: 298615150B
            FIXED CALLIPER
            right | yellow | F 97-EL080 185>> (PR:-450)
            FIXED CALLIPER Genuine Porsche Part - New (to order)
            # 5
            MPN: 97035242634
            CALLIPER WITHOUT BRAKE PADS
            right | yellow | F 97-EL070 483>> (PR:450)
            CALLIPER WITHOUT BRAKE PADS Genuine Porsche Part - New (to order)
            # 6
            MPN: 97035294905
            1 SET OF BRAKE PADS FOR DISC
            rear | brakes | comprising: | brake lining 4x |
            also use: | fasteners (PR:-450,-016)
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 6
            MPN: 97035294703
            1 SET OF BRAKE PADS FOR DISC
            rear | brakes | comprising: | brake lining 4x |
            also use: | fasteners | Discontinued part (PR:450)
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
            # 6
            MPN: 99135294803
            1 SET OF BRAKE PADS FOR DISC
            rear | brakes | comprising: | brake lining 4x |
            also use: | fasteners (PR:450)
            from £420.58
            from £420.58
            1 SET OF BRAKE PADS FOR DISC Genuine Porsche Part - New (to order)
            # 7
            MPN: 97035208600
            DAMPING PLATE
            from £12.66
            from £12.66
            DAMPING PLATE Genuine Porsche Part - New (to order)
            # 8
            MPN: 95861236550
            SENDER WIRE
            (pad wear indicator) (PR:-450)
            from £19.57
            from £19.57
            SENDER WIRE Genuine Porsche Part - New In stock
            # 8
            MPN: 97060914500
            SENDER WIRE
            (pad wear indicator) (PR:450)
            from £25.36
            from £25.36
            SENDER WIRE Genuine Porsche Part - New (to order)
            # 9
            MPN: 99906704001
            SCREW, CHEESE HD.
            M 12 X 1,5 X 95
            from £12.92
            from £12.92
            SCREW, CHEESE HD Genuine Porsche Part - New (to order)
            # 10
            MPN: 97035296100
            connecting line
            connecting line Genuine Porsche Part - New (to order)
            # 11
            MPN: 99635191500
            repair kit
            Protection caps | 32 MM | comprising: | Protection caps 4x | for | Fixed calliper 1x
            from £13.98
            from £13.98
            repair kit - Protection caps - 32 MM $ - D - MJ 2004>> Genuine Porsche Part - New (to order)
            # 12
            MPN: 8A0615273
            BLEEDER VALVE
            from £8.25
            from £8.25
            BLEEDER VALVE Genuine Porsche Part - New (to order)
            BLEEDER SCREW Genuine Lamborghini - New (to order)
            # 13
            MPN: 211611483
            DUST CAP
            from £3.60
            from £3.60
            dust cap - D >> - MJ 1983 Genuine Porsche Part - New (to order)
            DUST CAP Genuine Lamborghini - New (to order)
            # 14
            MPN: 97035295900
            SPRING
            from £39.59
            from £39.59
            SPRING Genuine Porsche Part - New (to order)
            # 15
            MPN: 00004311700
            BRAKE CYLINDER PASTE
            1 50-g tube
            brake cylinder paste - Discontinued part Genuine Porsche Part - New (to order)
            # 15
            MPN: 00004302000
            ASSEMBLY PASTE
            1 100-gramme tube
            Supersession
            Supersession
            Genuine Porsche Part (no longer available to order)
