porsche 2020 (panamera 971-1) dome strut parts diagram

801-015 - dome strut

Porsche 2020 (Panamera 971-1) Dome strut Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # 1
                                      MPN: 9A780547500
                                      DOME STRUT FIREWALL
                                      PL0L (Left-hand drive version)
                                      from £146.09
                                      from £146.09
                                      dome strut Genuine Porsche Part - New (to order)
                                      # 1
                                      MPN: 9A780547501
                                      DOME STRUT FIREWALL
                                      PL0R (Right-hand drive version)
                                      from £138.58
                                      from £138.58
                                      dome strut Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 9A780547701
                                      Reinforcement left Brace front
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 2
                                      MPN: 9A7 805 477 02
                                      REINFORCEMENT LEFT FRONT
                                      REINFORCEMENT LEFT FRONT
                                      REINFORCEMENT LEFT FRONT Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 971 805 477 C
                                      Reinforcement left Brace front
                                      Reinforcement left Brace front
                                      Reinforcement left Brace front Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 971805477D
                                      Reinforcement left Brace front
                                      Reinforcement left Brace front
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 2
                                      MPN: PAE805477
                                      Reinforcement left Brace front
                                      from £77.99
                                      from £77.99
                                      This part replaces part number 971805477D - and 1 more. Click to view details
                                      REINFORCEMENT Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 9A780547801
                                      Reinforcement right Brace front
                                      Reinforcement right Brace front
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 2
                                      MPN: PAE805478
                                      Reinforcement right Brace front
                                      from £39.94
                                      from £39.94
                                      This part replaces part number 971805478D - and 1 more. Click to view details
                                      REINFORCEMENT Genuine Porsche Part - New (to order)
                                      # 3
                                      MPN: 9A780122300
                                      BRACE LEFT SILL
                                      from £18.51
                                      from £18.51
                                      cross support Genuine Porsche Part - New (to order)
                                      # 3
                                      MPN: 9A780122400
                                      BRACE RIGHT SILL
                                      from £18.51
                                      from £18.51
                                      cross support Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: WHT007380
                                      CLAMPING NUT
                                      CLAMPING NUT Genuine Porsche Part - New (to order)
                                      # 5
                                      MPN: 9A780630301
                                      BRACE
                                      BRACE
                                      from £128.88
                                      from £128.88
                                      cross support Genuine Porsche Part - New (to order)
                                      # 5
                                      MPN: 971806303C
                                      BRACE
                                      BRACE
                                      from £122.22
                                      from £122.22
                                      BRACE Genuine Porsche Part - New (to order)
                                      # 5
                                      MPN: PAE806303
                                      BRACE ENGINE BAY
                                      from £123.77
                                      from £123.77
                                      BRACE Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 9A780322700
                                      BRACE LEFT REAR END
                                      P0K0 (Without alternative drive system)
                                      from £19.10
                                      from £19.10
                                      cross support Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 9A780322800
                                      BRACE RIGHT REAR END
                                      P0K0 (Without alternative drive system)
                                      from £19.10
                                      from £19.10
                                      cross support Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 9A780322701
                                      BRACE LEFT REAR END
                                      P0K3 (Hybrid propulsion system PHEV)
                                      from £19.10
                                      from £19.10
                                      cross support Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 9A780322801
                                      BRACE RIGHT REAR END
                                      P0K3 (Hybrid propulsion system PHEV)
                                      from £19.10
                                      from £19.10
                                      cross support Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 9A781458701
                                      BRACE LEFT REAR END
                                      from £125.23
                                      from £125.23
                                      cross support Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 9A781458801
                                      BRACE RIGHT REAR END
                                      from £125.23
                                      from £125.23
                                      cross support Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 971802019
                                      TUNNEL CROSS-PIECE
                                      P0E1 (Shorter wheelbase)
                                      TUNNEL CROSS-PIECE Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 971802019A
                                      TUNNEL CROSS-PIECE
                                      P0E2 (Long wheelbase)
                                      from £240.74
                                      from £240.74
                                      TUNNEL CROSS-PIECE Genuine Porsche Part - New (to order)
                                      # 10
                                      MPN: N 91249001
                                      HEXAGON BOLT WITH WASHER M10X45
                                      from £1.17
                                      from £1.17
                                      HEXAGON SCREW WITH WASHER Genuine Porsche Part - New (to order)
                                      # 11
                                      MPN: N 90440003
                                      HEXAGON HEAD BOLT (COMBI) M8X35
                                      from £1.54
                                      from £1.54
                                      BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
                                      HEXAGON HEAD BOLT M8X35-S1 Genuine Lamborghini - New In stock
                                      # 12
                                      MPN: N 10551901
                                      Hex collared bolt M10X30
                                      from £2.60
                                      from £2.60
                                      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                      HEXAGON FLANGE Genuine Lamborghini - New (to order)
                                      # 13
                                      MPN: N 10664503
                                      Hex collared bolt M8X45
                                      from £1.73
                                      from £1.73
                                      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: WHT008539
                                      HEXAGON COLLARED BOLT WITH M10X80 MULTI-POINT SOCKET HEAD (DUO)
                                      from £6.14
                                      from £6.14
                                      HEX BOLT WITH INTERNAL TORX Genuine Porsche Part - New (to order)
                                      # 15
                                      MPN: PAF912696
                                      HEXAGON NUT M10
                                      from £2.58
                                      from £2.58
                                      HEXAGON NUT Genuine Porsche Part - New (to order)
                                      # 16
                                      MPN: PAF107847
                                      HEX COLLARED BOLT M12X1,5X85 TO BE USED FOR ITEM: 7
                                      from £4.91
                                      from £4.91
                                      HEX COLLARED BOLT Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: N 0195307
                                      Hex collared bolt M8X25
                                      from £1.62
                                      from £1.62
                                      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New In stock
                                      HEXAGON FLANGE M8X25 Genuine Lamborghini - New In stock
                                      # 18
                                      MPN: N 91235101
                                      OVAL HEAD LOCATING BOLT WITH M8X20 MULTI-POINT SOCKET HEAD
                                      from £1.17
                                      from £1.17
                                      FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
                                      # 19
                                      MPN: N 10714101
                                      HEXAGON FLANGE SCREW M10X25
                                      from £2.34
                                      from £2.34
                                      HEXAGON FLANGE SCREW Genuine Porsche Part - New (to order)
                                      HEXAGON FLANGE Genuine Lamborghini - New (to order)
                                      # 20
                                      MPN: N 91157202
                                      SOCKET HEAD COLLARED BOLT WITH M8X30 INNER MULTIPOINT HEAD
                                      from £2.04
                                      from £2.04
                                      SOCKET HD. SCREW WITH POLYGON Genuine Porsche Part - New (to order)
                                      12-POINT SOCKET M8X30 Genuine Lamborghini - New In stock
                                      # 21
                                      MPN: 971825259A
                                      AIR DUCT FOR LEFT BRAKE COOLING
                                      AIR DUCT FOR LEFT BRAKE COOLING
                                      from £19.26
                                      from £19.26
                                      BRAKE COOLING AIR Genuine Porsche Part - New (to order)
                                      # 21
                                      MPN: 971825259D
                                      AIR DUCT FOR LEFT BRAKE COOLING
                                      from £18.48
                                      from £18.48
                                      AIR DUCT FOR BRAKE COOLING Genuine Porsche Part - New (to order)
                                      # 21
                                      MPN: 971825260A
                                      AIR DUCT FOR RIGHT BRAKE COOLING
                                      from £19.26
                                      from £19.26
                                      BRAKE COOLING AIR Genuine Porsche Part - New (to order)
                                      # 22
                                      MPN: N 91244301
                                      Hexagon collared bolt with M12X1.5X90 hexagon socket head (duo)
                                      from £3.55
                                      from £3.55
                                      HEX BOLT WITH TORX HEAD Genuine Porsche Part - New In stock
                                      # 23
                                      MPN: 971907179A
                                      BRACKET RIGHT
                                      from £9.31
                                      from £9.31
                                      BRACKET Genuine Porsche Part - New (to order)
                                      # 24
                                      MPN: N 10118104
                                      HEXAGON NUT M5 TO BE USED FOR ITEM: 23
                                      from £1.15
                                      from £1.15
                                      HEX. NUT Genuine Porsche Part - New (to order)
