porsche 2020 (panamera 971-1) water box parts diagram

813-000 - water box

Porsche 2020 (Panamera 971-1) water box Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                        #
                                        Part number
                                        Description
                                        Key
                                        Price
                                        # 1
                                        MPN: 971819401B OK1
                                        PLENUM CHAMBER COVER LHD - MATT BLACK
                                        PL0L (Left-hand drive version)
                                        from £46.18
                                        from £46.18
                                        This part replaces part number 971819401B
                                        MATT BLACK Genuine Porsche Part - New (to order)
                                        # 1
                                        MPN: 971819401C OK1
                                        PLENUM CHAMBER COVER RHD - MATT BLACK
                                        PL0R (Right-hand drive version)
                                        from £46.18
                                        from £46.18
                                        This part replaces part number 971819401C
                                        MATT BLACK Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 9A781951000
                                        WATER BOX LEFT FIREWALL LOWER
                                        water box Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 9A781953000
                                        WATER BOX RIGHT FIREWALL LOWER
                                        PL0L (Left-hand drive version)
                                        water box Genuine Porsche Part - New (to order)
                                        # 2
                                        MPN: 9A781953010
                                        WATER BOX RIGHT FIREWALL LOWER
                                        PL0R (Right-hand drive version)
                                        water box Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: 9A781951100
                                        WATER BOX LEFT FIREWALL LOWER
                                        from £26.09
                                        from £26.09
                                        water box Genuine Porsche Part - New (to order)
                                        # 3
                                        MPN: 9A781951200
                                        WATER BOX RIGHT FIREWALL LOWER
                                        from £26.09
                                        from £26.09
                                        water box Genuine Porsche Part - New (to order)
                                        # 4
                                        MPN: 9A781551700
                                        WATER BOX UPPER FIREWALL ENTFALLTEIL
                                        from £53.69
                                        from £53.69
                                        water box Genuine Porsche Part - New (to order)
                                        # 4
                                        MPN: PAE815517
                                        WATER BOX UPPER FIREWALL
                                        from £56.51
                                        from £56.51
                                        water box Genuine Porsche Part - New (to order)
                                        # 4
                                        MPN: PAE815517A
                                        WATER BOX UPPER FIREWALL
                                        from £56.51
                                        from £56.51
                                        water box Genuine Porsche Part - New (to order)
                                        # 5
                                        MPN: 9A781952300
                                        WATER BOX CENTER FIREWALL
                                        water box Genuine Porsche Part - New (to order)
                                        # 6
                                        MPN: 9A781953100
                                        SEAL FOR WATER BOX LEFT ZU POS.2
                                        SEAL FOR WATER BOX Genuine Porsche Part - New (to order)
                                        # 6
                                        MPN: 9A781953200
                                        SEAL FOR WATER BOX RIGHT ZU POS.2
                                        SEAL FOR WATER BOX Genuine Porsche Part - New (to order)
                                        # 7
                                        MPN: 9A782060900
                                        GROMMET REFRIGERANT LINE
                                        GROMMET Genuine Porsche Part - New (to order)
                                        # 8
                                        MPN: 95857241900
                                        WATER DRAIN VALVE
                                        from £6.45
                                        from £6.45
                                        WATER DRAIN VALVE Genuine Porsche Part - New (to order)
                                        # 9
                                        MPN: 971819236
                                        FOAM PART WATER BOX
                                        from £22.25
                                        from £22.25
                                        foam part Genuine Porsche Part - New (to order)
                                        # 10
                                        MPN: 971819238
                                        FOAM PART WATER BOX
                                        from £17.41
                                        from £17.41
                                        foam part Genuine Porsche Part - New (to order)
                                        # 11
                                        MPN: 9A781923900
                                        FOAM PART WATER BOX
                                        foam part Genuine Porsche Part - New (to order)
                                        # 12
                                        MPN: 9A781999700
                                        FOAM PART WATER BOX
                                        foam part Genuine Porsche Part - New (to order)
                                        # 13
                                        MPN: 9A781536100
                                        FOAM PART WATER BOX
                                        from £9.87
                                        from £9.87
                                        foam part Genuine Porsche Part - New (to order)
                                        # 14
                                        MPN: 9A781536200
                                        FOAM PART WATER BOX
                                        from £6.58
                                        from £6.58
                                        foam part Genuine Porsche Part - New (to order)
                                        # 15
                                        MPN: N 10430104
                                        Hexagon socket flat M5X16 head bolt
                                        from £0.84
                                        from £0.84
                                        HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                                        HEXALOBULAR SOCKET PAN HEAD SCREW Genuine Lamborghini - New (to order)
                                        # 16
                                        MPN: N 91042301
                                        OVAL HEXAGON SOCKET HEAD BOLT M6X16
                                        from £0.63
                                        from £0.63
                                        This part replaces part number 99907313001
                                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New In stock
                                        HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New (to order)
                                        # 17
                                        MPN: N 91191401
                                        OVAL HEXAGON SOCKET HEAD BOLT M6X18
                                        from £0.54
                                        from £0.54
                                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                                        OVAL HEXAGON SOCKET HEAD BOLT Genuine Lamborghini - New (to order)
                                        # 18
                                        MPN: N 90495301
                                        HEXAGON NUT D5 PLASTIC NUT
                                        from £0.99
                                        from £0.99
                                        HEX. NUT Genuine Porsche Part - New (to order)
                                        HEX.NUT D5 Genuine Lamborghini - New (to order)
                                        # 19
                                        MPN: N 90627102
                                        SPEED NUT, SELF-LOCKING M6X23,4X16,5
                                        from £2.07
                                        from £2.07
                                        SPEED NUT, SELF-LOCKING Genuine Porsche Part - New (to order)
                                        SNAP NUT CLAMP Genuine Lamborghini - New (to order)
                                        # 20
                                        MPN: N 90475903
                                        SPEED NUT M5X13,6X11,5
                                        from £0.76
                                        from £0.76
                                        SPEED NUT Genuine Porsche Part - New (to order)
                                        SNAP NUT CLAMP M5X13.6X11.5 Genuine Lamborghini - New In stock
                                        # 21
                                        MPN: N 90857202
                                        Bungs 26
                                        PA8C (Standard equipment) | PA8F (S equipment) | PA8H (Turbo equipment) | P1A2 (Petrol direct fuel injection (DFI))
                                        from £0.71
                                        from £0.71
                                        PLUG Genuine Porsche Part - New (to order)
                                        # 22
                                        MPN: 971863931
                                        DAMPING LEFT COVER WATER BOX
                                        from £30.04
                                        from £30.04
                                        sound absorber Genuine Porsche Part - New (to order)
                                        # 22
                                        MPN: 971863932
                                        DAMPING RIGHT COVER WATER BOX
                                        from £30.04
                                        from £30.04
                                        sound absorber Genuine Porsche Part - New (to order)
                                        # 23
                                        MPN: 971819976
                                        DRAIN TUBE
                                        from £7.66
                                        from £7.66
                                        DRAIN TUBE GROMMET Genuine Porsche Part - New (to order)
                                        # 23
                                        MPN: 971819975
                                        DRAIN TUBE
                                        PL0R (Right-hand drive version)
                                        from £7.66
                                        from £7.66
                                        DRAIN TUBE GROMMET Genuine Porsche Part - New (to order)
