P1BK (4-corner air suspension with electronic shock absorption control) | PK8D (Wagon/Avant) | PK8S (Sports sedan) | PK8X (Avant allroad)
porsche 2023 (taycan 9j1-1) gas strut parts diagram

502-000 - GAS STRUT

Porsche 2023 (Taycan 9J1-1) Gas strut Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: 9J1513035C
                  Shock Absorbers
                  Shock Absorbers
                  from £658.72
                  from £658.72
                  Shock Absorbers Genuine Porsche Part - New (to order)
                  # 1
                  MPN: 9J1513035E
                  GAS SHOCK ABSORBER
                  PK8S (Sports sedan) | PK8D (Wagon/Avant)
                  from £542.64
                  from £542.64
                  GAS SHOCK ABSORBER Genuine Porsche Part - New (to order)
                  # 1
                  MPN: 9J0513035
                  Shock Absorbers
                  Shock Absorbers
                  from £683.64
                  from £683.64
                  Shock Absorbers Genuine Porsche Part - New (to order)
                  # 1
                  MPN: 9J0513035A
                  Shock Absorbers
                  PK8X (Avant allroad)
                  from £563.17
                  from £563.17
                  Shock Absorbers Genuine Porsche Part - New (to order)
                  # 2
                  MPN: PAD411109
                  RING
                  from £10.26
                  from £10.26
                  RING Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 971512137
                  PROTECTIVE SLEEVE
                  from £12.26
                  from £12.26
                  BOOT Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 9J1512131B
                  STOP BUFFER
                  PK8S (Sports sedan) | PK8D (Wagon/Avant)
                  from £22.91
                  from £22.91
                  STOP BUFFER Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 9J0512131A
                  STOP BUFFER
                  PK8X (Avant allroad)
                  from £22.91
                  from £22.91
                  STOP BUFFER Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 9J1513353
                  SHOCK ABSORBER BEARING
                  from £42.40
                  from £42.40
                  SHOCK ABSORBER BEARING Genuine Porsche Part - New (to order)
                  # 6
                  MPN: WHT004985
                  HEX. NUT M14X1.5
                  from £2.42
                  from £2.42
                  HEX. NUT Genuine Porsche Part - New (to order)
                  # 7
                  MPN: PAF107169
                  HEX COLLARED BOLT M12X1,5X170X90
                  from £8.18
                  from £8.18
                  HEX COLLARED BOLT Genuine Porsche Part - New (to order)
                  # 8
                  MPN: N 90966402
                  HEXAGON COLLAR NUT M12X1,5 SELF-LOCKING
                  HEXAGON COLLAR NUT M12X1,5 SELF-LOCKING
                  Supersession
                  Supersession
                  Genuine Porsche Part (no longer available to order)
                  # 8
                  MPN: PAF909664
                  HEXAGON COLLAR NUT M12X1,5 SELF-LOCKING
                  from £1.78
                  from £1.78
                  This part replaces part number N 90966402
                  SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
                  # 9
                  MPN: N 10728502
                  Hex collared bolt M10X42
                  from £1.78
                  from £1.78
                  BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
                  HEXAGON FLANGE M10X42 Genuine Lamborghini - New (to order)
                  # 10
                  MPN: 9J1616025A
                  SPRING CYLINDER LEFT
                  from £741.03
                  from £741.03
                  SPRING CYLINDER Genuine Porsche Part - New (to order)
                  # 10
                  MPN: 9J1616026A
                  spring cylinder right
                  spring cylinder right
                  from £749.86
                  from £749.86
                  SPRING CYLINDER Genuine Porsche Part - New (to order)
                  # 10
                  MPN: 9J1616026C
                  SPRING CYLINDER RIGHT REAR AXLE
                  from £716.53
                  from £716.53
                  SPRING CYLINDER Genuine Porsche Part - New (to order)
                  # 11
                  MPN: 9J1 616 297
                  SPRING SUPPORT
                  SPRING SUPPORT
                  SPRING SUPPORT Genuine Porsche Part - New (to order)
                  # 11
                  MPN: 9J1616297A
                  SPRING SUPPORT
                  from £13.66
                  from £13.66
                  SPRING SUPPORT Genuine Porsche Part - New (to order)
                  # 12
                  MPN: 9J1971289A
                  WIRING HARNESS FOR SELF-LEVELLING SUSPENSION
                  from £31.55
                  from £31.55
                  LOOM Genuine Porsche Part - New (to order)
                  # 13
                  MPN: 9J0616297A
                  SPRING SUPPORT D >>- 18.07.2021
                  PK8X (Avant allroad)
                  from £6.85
                  from £6.85
                  SPRING SUPPORT Genuine Porsche Part - New (to order)
                  # 13
                  MPN: 9J0616297B
                  SPRING SUPPORT D - 19.07.2021>>
                  PK8X (Avant allroad)
                  from £6.85
                  from £6.85
                  SPRING SUPPORT Genuine Porsche Part - New (to order)
                  # 14
                  MPN: 9J1616640
                  REPAIR SET FOR AIR CHANNEL
                  from £88.96
                  from £88.96
                  REPAIR SET FOR AIR CHANNEL Genuine Porsche Part - New (to order)
