porsche 2026 (taycan 9j1-2) air conditioning heat exchanger parts diagram

814-300 - Air conditioning heat exchanger

Porsche 2026 (Taycan 9J1-2) Air conditioning heat exchanger Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: PAD816112D
                    HEAT EXCHANGER LHD
                    from £495.81
                    from £495.81
                    HEAT EXCHANGER Genuine Porsche Part - New (to order)
                    # 1
                    MPN: PAD816112F
                    HEAT EXCHANGER RHD
                    from £495.81
                    from £495.81
                    HEAT EXCHANGER Genuine Porsche Part - New (to order)
                    # 2
                    MPN: PAD820750
                    REFRIGERANT LINE LHD
                    from £131.72
                    from £131.72
                    REFRIGERANT LINE Genuine Porsche Part - New (to order)
                    # 2
                    MPN: 9JA820750A
                    REFRIGERANT LINE RHD
                    from £131.72
                    from £131.72
                    REFRIGERANT LINE Genuine Porsche Part - New (to order)
                    # 3
                    MPN: 9A757374903
                    O-RING 16,25X2,5
                    from £3.74
                    from £3.74
                    O-RING Genuine Porsche Part - New (to order)
                    # 4
                    MPN: PAB260749
                    O-RING 7,6X2,5
                    from £4.18
                    from £4.18
                    O-RING Genuine Porsche Part - New (to order)
                    # 5
                    MPN: 95557374900
                    O-RING 9.5X2.5-N
                    from £3.99
                    from £3.99
                    O-RING Genuine Porsche Part - New In stock
                    # 6
                    MPN: PAD820776
                    SPACER SLEEVE
                    from £2.00
                    from £2.00
                    SPACER SLEEVE Genuine Porsche Part - New (to order)
                    # 7
                    MPN: N 90737107
                    OVAL HEXAGON SOCKET HEAD BOLT M6X12
                    from £0.61
                    from £0.61
                    FILLISTER HD. SCREW WITH Genuine Porsche Part - New (to order)
                    HEXALOBULAR SOCKET Genuine Lamborghini - New (to order)
                    # 8
                    MPN: N 10700201
                    HEXAGON SOCKET HEAD BOLT M6X22
                    from £1.15
                    from £1.15
                    HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
                    HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
                    # 9
                    MPN: PAF106322
                    Hexagon socket flat M6X30 head bolt
                    from £0.88
                    from £0.88
                    HEXAGON SOCKET FLAT HEAD BOLT Genuine Porsche Part - New (to order)
