porsche 2019 (991-2) engine (oil press./lubrica.) parts diagram

104-005 - ENGINE (OIL PRESS./LUBRICA.)

Porsche 2019 (991-2) ENGINE (OIL PRESS./LUBRICA.) Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: 94860621300
          OIL PRESSURE GAUGE SENDER
          from £144.13
          from £144.13
          OIL PRESSURE GAUGE SENDER Genuine Porsche Part - New (to order)
          # 2
          MPN: 94810702200
          OIL FILTER
          Complete
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 3
          MPN: 94810717500
          GASKET
          HEATER CORE
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 4
          MPN: 99970763440
          O-RING
          18,50X4,00NX
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 5
          MPN: 99970763540
          O-RING
          21,00X4,00NX
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 6
          MPN: 99970759440
          O-RING
          11,00X4,00N
          from £7.14
          from £7.14
          O-RING Genuine Porsche Part - New (to order)
          # 7
          MPN: 9A110746501
          SEAL RING
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 8
          MPN: 99970759540
          O-RING
          20,00X4,00N
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 9
          MPN: 9A210701500
          oil filler tube
          with: | O-Ring
          from £28.78
          from £28.78
          oil filler tube Genuine Porsche Part - New (to order)
          # 10
          MPN: 99970753040
          O-RING
          34,52X3,53
          O-RING Genuine Porsche Part - New (to order)
          # 11
          MPN: 9A210704500
          oil-conducting housing
          complete | No longer use the part here
          oil-conducting housing Genuine Porsche Part - New (to order)
          # 11
          MPN: 9A210701000
          oil-conducting housing
          complete |
          D >> - 03.12.2015 | Discontinued part
          oil-conducting housing Genuine Porsche Part - New (to order)
          # 11
          MPN: 9A210701001
          oil-conducting housing
          complete | D - 04.12.2015>>
          oil-conducting housing Genuine Porsche Part - New (to order)
          # 11
          MPN: 0PB115401A
          oil-conducting housing
          Complete
          from £1,210.38
          from £1,210.38
          oil-conducting housing Genuine Porsche Part - New (to order)
          # 12
          MPN: 90038512501
          TORX SCREW
          BM6X45
          from £2.32
          from £2.32
          TORX SCREW Genuine Porsche Part - New (to order)
          # 13
          MPN: 90038502701
          TORX SCREW
          BM6X70
          from £1.73
          from £1.73
          Torx screw - M 6 X 70 Genuine Porsche Part - New (to order)
          # 14
          MPN: 94810722200
          OIL FILTER ELEMENT
          also use: 1x 94810732200
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 15
          MPN: 94810732200
          SEAL RING
          91,0X4,0
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 16
          MPN: 9A210745500
          HEATER CORE
          (PR:030,475, 477)
          from £449.87
          from £449.87
          HEATER CORE Genuine Porsche Part - New (to order)
          # 16
          MPN: 9A210745520
          HEATER CORE
          (PR:031,352)
          from £597.31
          from £597.31
          HEATER CORE Genuine Porsche Part - New (to order)
          # 17
          MPN: 99907341601
          BOLT WITH WASHER
          M6X20
          from £1.78
          from £1.78
          BOLT WITH WASHER Genuine Porsche Part - New (to order)
          # 18
          MPN: 9A110704001
          oil separator
          Discontinued part
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 18
          MPN: 9A110704002
          oil separator
          oil separator Genuine Porsche Part - New (to order)
          # 19
          MPN: 9P1115423
          SEALING CAP
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 20
          MPN: 90038501901
          TORX SCREW
          BM6X20
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 21
          MPN: 9A210721500
          BRACKET
          OIL FILLER NECK
          from £10.06
          from £10.06
          BRACKET Genuine Porsche Part - New (to order)
          # 22
          MPN: 99959188201
          SPEED NUT
          M6
          from £2.29
          from £2.29
          speed nut - M6 Genuine Porsche Part - New (to order)
          # 23
          MPN: 99991928301
          OVAL-HEAD SCREW
          6,0X18,0
          from £1.49
          from £1.49
          OVAL-HEAD SCREW Genuine Porsche Part - New (to order)
          # 24
          MPN: 99950788640
          BRACKET FOR HOSE
          4,8-8,0
          from £0.80
          from £0.80
          BRACKET FOR HOSE Genuine Porsche Part - New (to order)
          # 25
          MPN: 9P1115310
          OIL HOSE
          from £33.55
          from £33.55
          OIL HOSE Genuine Porsche Part - New (to order)
          # 26
          MPN: 99951269509
          HOSE CLAMP
          B38X12
          from £1.60
          from £1.60
          HOSE CLAMP Genuine Porsche Part - New (to order)
          # 27
          -
          OIL FILLER NECK
          engine oil |
          see illustration: 105-020
          # 28
          MPN: 00004330521
          engine oil
          1,0ltr. | EXXON MOBIL 1 | 0W-40 |
          D >> - 13.05.2018
          from £17.76
          from £17.76
          engine oil Mobil 1 0W-40 Genuine Porsche Part - New (to order)
          # 28
          MPN: 00004321093
          engine oil
          1,0ltr. | EXXON MOBIL 1 | 0W-40 | ESP X 3 | D - 14.05.2018>>
          from £15.78
          from £15.78
          engine oil Genuine Porsche Part - New (to order)
          # 28
          MPN: 00004321093
          engine oil
          1,0ltr. | For vehicles with a EXXON MOBIL 1 | petrol particulate filter 0W-40 | ESP X 3 (PR:7CP)
          from £15.78
          from £15.78
          engine oil Genuine Porsche Part - New (to order)
          # 29
          MPN: 00004330522
          engine oil
          20ltr. | EXXON MOBIL 1 | 0W-40 |
          D >> - 13.05.2018
          from £319.68
          from £319.68
          engine oil Genuine Porsche Part - New (to order)
